Explore EX90 specifications

Powertrain options. Key dimensions. Standard features and upgrades. All you need to find the right Volvo car for you.

  •  Image



Platform

Twin Motor

  • Fuel type Electric
  • Driveline AWD
  • Transmission Automatic
  • Electric system 800 V
  • Number of seats 7
  • Weight (Running Order Mass) 2764 kg
  • Gross vehicle weight 3340 kg
  • Trailer max weight 2200 kg
  • Roof load max weight 100 kg

Performance

  • Electric Range Up to 600 km
  • Electric energy consumption 19.2 kWh/100km
  • Power 335 kW / 456 hp
  • Max torque 670 Nm
  • 0-100 km/h 5.5 s
  • Top speed 180 km/h
  • Environmental Classification Euro6e

Charging

  • Battery energy (nominal) 106 kWh
  • Battery charging duration 0-100% (3-phase 16A) 11 h
  • Battery charging duration 10-80% (DC 350 kW) 22 m

Twin Motor Performance

  • Fuel type Electric
  • Driveline AWD
  • Transmission Automatic
  • Electric system 800 V
  • Number of seats 7
  • Weight (Running Order Mass) 2725 kg
  • Gross vehicle weight 3340 kg
  • Trailer max weight 2200 kg
  • Roof load max weight 100 kg

Performance

  • Electric Range Up to 600 km
  • Electric energy consumption 19.2 kWh/100km
  • Power 500 kW / 680 hp
  • Max torque 870 Nm
  • 0-100 km/h 4.2 s
  • Top speed 180 km/h
  • Environmental Classification Euro6e

Charging

  • Battery energy (nominal) 106 kWh
  • Battery charging duration 0-100% (3-phase 16A) 11 h
  • Battery charging duration 10-80% (DC 350 kW) 22 m

Features and upgrades

  • Whiplash injury protection
    PlusUltra
  • Inflatable Curtain
    PlusUltra
  • Side impact protection
    PlusUltra
  • ISOFIX mounting points, rear seat
    PlusUltra
  • Safety belts
    PlusUltra
  • Digital key plus
    PlusUltra
  • Key card
    PlusUltra
  • Dual-stage airbags
    PlusUltra
  • Knee airbag, driver side
    PlusUltra
  • Alarm
    PlusUltra
  • Central locking with power release and soft close
    PlusUltra
  • Integrated booster cushion
    PlusUltra
  • Temporary mobility kit
    PlusUltra
  • Tempered side and rear windows
    PlusUltra
  • Laminated side and rear windows
    PlusUltra
  • Warning triangle
    PlusUltra

  • Rain sensor
    PlusUltra
  • Door opening alert
    PlusUltra
  • Core computing
    PlusUltra
  • Driver recognising
    PlusUltra
  • Run-off road Mitigation
    PlusUltra
  • Collision avoidance and mitigation
    PlusUltra
  • Pedestrian, cyclist and scooter steering avoidance
    PlusUltra
  • Rear cross traffic alert with low-speed auto brake
    PlusUltra
  • Intersection autobrake
    PlusUltra
  • Connected Safety
    PlusUltra
  • Road Sign Information
    PlusUltra
  • Volvo Assistance
    PlusUltra
  • 9-inch driver display
    PlusUltra
  • 14.5-inch centre display
    PlusUltra
  • Emergency stop assist and safety call
    PlusUltra
  • 360° camera with 3D view
    PlusUltra
  • Occupant sensing
    PlusUltra
  • Advanced sensing technology
    PlusUltra
  • Drive modes Performance
    PlusUltra
  • LED headlights
    PlusUltra
  • High Definition Pixel lights
    PlusUltra
  • Headlight cleaning
    PlusUltra
  • Pilot Assist
    PlusUltra
  • Head-up display
    PlusUltra
  • BLIS™ (Blind Spot Information System)
    PlusUltra
  • Auto-dimmed rear view mirrors
    PlusUltra
  • Active chassis
    PlusUltra
  • Chassis
    PlusUltra
  • Tyre pressure monitoring
    PlusUltra
  • Active air suspension
    PlusUltra
  • Power adjustable steering column
    PlusUltra
  • Park Pilot Assist
    PlusUltra

  • Humidity sensor
    PlusUltra
  • Electric cabin heater and cooler
    PlusUltra
  • Third row air conditioning
    PlusUltra
  • Four-zone climate system
    PlusUltra
  • Heat pump
    PlusUltra
  • Air purifier and remote cabin pre-cleaning
    PlusUltra
  • Heated steering wheel
    PlusUltra
  • Wiper blades with integrated washers
    PlusUltra

  • Bluetooth® connection
    PlusUltra
  • Over-the-air updates (OTA)
    PlusUltra
  • Volvo Cars App
    PlusUltra
  • 5G capability
    PlusUltra
  • USB-C ports
    PlusUltra
  • In-car communication
    PlusUltra
  • Wireless Apple CarPlay
    PlusUltra
  • Bose Premium Sound System
    PlusUltra
  • Bowers & Wilkins High Fidelity audio system
    PlusUltra
  • Wireless phone charging
    PlusUltra
  • Google Assistant, Google Maps and Google Play Store
    PlusUltra

  • Jewel-design media rotary knob
    PlusUltra
  • Jewel-design air intake controls
    PlusUltra
  • Charcoal headlining
    PlusUltra
  • Dawn headlining
    PlusUltra
  • Birch decor
    PlusUltra
  • Tailored dashboard and door panels
    PlusUltra
  • Nordico upholstery
    PlusUltra
  • Nordico upholstery with ventilation
    PlusUltra
  • Premium textile interior cabin floor mats
    PlusUltra
  • Interior illumination, high level
    PlusUltra
  • Tailored steering wheel
    PlusUltra

  • Front load compartment
    PlusUltra
  • Power tailgate
    PlusUltra
  • Load cover, second row
    PlusUltra

  • Body-coloured covered grille
    PlusUltra
  • Panoramic roof, fixed
    PlusUltra
  • Electrochromic panoramic roof
    PlusUltra
  • Door mirror covers, high-gloss black
    PlusUltra
  • Tinted rear windows
    PlusUltra
  • 20" 5-spoke glossy black diamond cut, rear
    PlusUltra
  • 22" 5-spoke glossy black diamond cut, rear
    PlusUltra
  • 22" 5-Y spoke glossy black forged, rear
    PlusUltra
  • 20" 5-spoke glossy back diamond cut
    PlusUltra
  • 22" 5-spoke glossy black diamond cut
    PlusUltra
  • 22" 5-Y spoke glossy black diamond cut, forged
    PlusUltra
  • Body-coloured door handles
    PlusUltra
  • Flush door handles with ground lighting
    PlusUltra
  • High-gloss black side window trim
    PlusUltra
  • Roof rails, glossy black
    PlusUltra
  • Lower door mouldings, High-gloss Black
    PlusUltra

  • 11kW On-Board Charger (OBC)
    PlusUltra
  • Home charging cable, mobile 7m (10A)
    PlusUltra

  • Shift-by-wire single speed transmission
    PlusUltra

  • Front seat massage
    PlusUltra
  • Power driver seat with memory and easy entry/exit
    PlusUltra
  • Power passenger seat
    PlusUltra
  • Ventilated seats
    PlusUltra
  • Heated rear seats
    PlusUltra
  • 7 seats
    PlusUltra
  • Power side bolsters
    PlusUltra
  • Power 4-way lumbar support
    PlusUltra
  • Manual cushion extensions, driver and passenger
    PlusUltra

Car dimensions

Exterior

  • Vehicle height at curb weight with one person 1744 mm
  • Width (mirrors incl) 2113 mm
  • Front track width 1672 mm
  • Width 1964 mm
  • Width (mirrors folded) 2039 mm
  • Rear track width 1666 mm
  • Vehicle length 5037 mm
  • Wheelbase 2985 mm
  • Turning circle 12 m

Interior

  • Head room front with panoramic roof 1075 mm
  • Shoulder room rear 1467 mm
  • Hip room front 1422 mm
  • Head room rear with panoramic roof 1056 mm
  • Leg room front 1039 mm
  • Hip room rear 1434 mm
  • Shoulder room front 1475 mm
  • Leg room rear 926 mm

Storage

  • Cargo floor width between wheel housing 1130 mm
  • Third seatback to tailgate top of third seatback 378 mm
  • First seatback to tailgate - top of first seatback 1909 mm
  • Luggage capacity (max) - third row up 377 l
  • Luggage capacity (max) - second row up 1045 l
  • Luggage capacity (max) - seats folded 2082 l
  • Cargo capacity (front) 46 l

Features depicted may not be standard or available for all markets, equipment levels, powertrain options and model years. Google services are enabled through a digital services package that is included for four years. After this period, new terms and fees will apply if you choose to renew. Google, Google Maps and Google Play are trademarks of Google LLC.

*The Maximum Retail Price (MRP) includes GST and excludes on road costs which may vary between Volvo retailers. The MRP also includes access to the following digital services for a period of 4 years: Google Assistant, Google Maps, Google Play Store, the Volvo Car App remote functions and data (subject to the fair use policy) for the said services. After that period a prolongment or renewal will be offered and a subscription fee will be charged. The MRP excludes accessory items that require you to contact a Volvo retailer for a price, does not take into account the effect of any fees, discount, rebate or promotion that may be available from time to time unless stated otherwise. Pricing, models, specifications, features, characteristics, capabilities, packages and optional extras featured are subject to change without notice. Volvo Car New Zealand reserves the right to vary the MRP and make such changes to its products. The final sale price will be agreed by you with your preferred authorised Volvo retailer and set out in the vehicle sale agreement between you and the Volvo retailer. Please always consult an authorised Volvo retailer to obtain the latest current and accurate information.

**Figures according to WLTP data obtained under specific testing conditions unless stated otherwise and are subject to change without notice. Factors including but not limited to driving style, road and traffic conditions, environmental influences, vehicle condition and accessories fitted, means in the real world the range you experience can differ from that advertised. Advertised figures are meant for comparison purposes.
